Sessiz S40 M800 Lithium Battery 4Kw 10.2kw

Silent S40 M800 Lithium 4Kw 10.2kw

Full sine supply power 220V/50Hz

4 Kw/4000W Continuous Supply Power

7 Kw/7000W Instantaneous Peak Power

10.2 Kw Energy Storage Capacity

3000 Discharge Possibility

800 Ah 12.8V Lithium (Lifepo4)

Battery Maintenance and Protection Program

Automatic Activation – Automatic Charging

220 V 20ah Charging System

Lithium battery - 120 Kg

40x70x45h cm

Preparation for Charging from Solar Panel

Preliminary Preparation for Charging from the Vehicle

Mobile System

Silent Fan Cooling System

100% Silent System

Usage Plan:

It runs the combi/heating boiler for 4-5 days continuously.

42 Inch LED TV operates continuously for 4-5 days.

Large Size Refrigerator runs 50-60 hours.

It runs a 10w lamp for 700-900 hours continuously.

It runs the desktop computer for 4-6 days continuously.

Tea Maker, Mixer, Toaster, Heater, Hair dryer for short-term use

It provides individual solutions in the use of vacuum cleaners, hilti and drill type tools.

Concurrent Plan:

It provides 40-60 hours of use in the form of combi boiler, TV, PC, Lighting, Modem and Refrigerator.

Compatible Solar Energy System Package:

12 pieces of 340w monocrystalline panels

2 x 80ah Mppt Regulators

(20+20) 40 m 6mm Solar cable

12pcs MC4 socket set

2pcs Mc4 Socket Set x 2

2x4cm box profile 8m.

8 size nut-screw – 50 pieces

Panel dimensions and weight: 1666*1001*35 / 19kg

Energy to be Produced: Produces 7-10Kw energy per day.

Recycling: 4-6 Years

Lifespan: 20+years

Compatible Wind Energy Package:

Technicial Specifications

Power and maximum rpm: 2200 watts/hour, 550 rpm

Wing length: 1.22 meters

Rated wind speed: 13 (m/s)

Wing swept area: 4.676 m²

Rotor type and diameter: 3 blades, 2.5 meters Current 3 Phase-AC

Alternator: 24V, 48V 3 Phase AC Fixed installed, without female box, you are welcome

Hub tension: Aluminum Alloy Construction

Charging control: 2200 Watt, 24V, 48V

Initial wind speed: 3 m/s

Compatible Voltage: 24V 5000 Watt, 48V

Charging wind speed: 3.5 m/s

Wing material: Composite products

Maximum sound level: 40 dB

Total turbine weight: 25 kg

Turning angle to wind: 360°

Lifespan: 25 years

Brake system: EM Brake

Warranty: 2 years

Battery system: Gel or Lithium-ion battery

Wing weight: 1.4 kg

Tower material and can be classified: Steel, 7 meters

Vehicle Charging Package:

30ah DC Charger

(5+5) 10mt. cable

Socket set

Data display

NOTE: The auto electrician directly assembles the battery terminals.
